rfid standard PVC card

Product

RFID smart card

Material

PVC,PET,ABS,Paper

Color

-Screen printing- Silver/Gold silk

-Screen printing background

-Full color offset printing- Silk   etc others color are vailable for customizing

Standard

ISO14443, ISO15693, ISO 18000, etc.

Dimension

85.5mm*54mm*0.84±0.02mm(CR80: credit card size) or on your demand

Thickness

ISO standard 0.76mm, else available 0.3mm/0.38mm/0.5mm/0.76mm, or on demand

Frequency

125 KHz, 13.56 MHz, 860-960 MHz

Protocal

ISO/IEC 11784/785, ISO14443A, ISO15693, ISO18000-6C

Chip

LF: TK 4100, EM 4200, EM 4305, T5577, HID, HITAG 1, HITAG 2, HITAG S, etc
HF: FM11RF08, MF S50, FM11RF32N, MF S70(4KB), ICODE SLI, ICODE SLI-X, ICODE SLI-S, MF UTL EV1, MF UTL-C, MF D21, MF D41, MF D81, MF PLUS S, MF PLUS X, MF PLUS X, TAG-IT, NTAG 213, NTAG 215, NTAG 216, TOPAZ512, etc
UHF: U-CODE EPC G2, U-CODE G2XL, U-CODE G2XM, Alien H3, Alien H4, Monza 3, Monza 4, Monza 5, etc

Memory

512 bits, 128 bits, 1K Byte, 4K Byte, 144 Byte, 888 Byte, etc

Antenna

LF: Pre-winding Copper Coli, AL Etching

HF: AL Etching, Pre-winding Copper Coil, Altrasonic Embeding
UHF: AL Etching

Read Range

Related to reader

Work Temperature

-25℃ ~ +55℃

Store Temperature

-25℃ ~ +65℃

Craft

3M adhesive back side

CMYK Offset printing, Silk printing

Encoding with your data including URL, Website etc

Serial Number including UID, Laser number

Gold/silver hot stamping

Embossed number

Gold/silver wire drawing

Gold/sliver silk-screen printing

UV spot ,Barcode,QR code,Anti-metal Material ,Scratch Off Panel, Signature Panel

Applications

Access Control & Security, Time Attendance, Logical Access, Public Transport, City Card, etc.
